Silicotungstic acid, a key member of the polyoxometalate family, showcases significant application potential in materials science, chemical engineering, and biomedicine due to its unique molecular structure and excellent chemical properties. It is an inorganic compound composed of tungsten, silicon, hydrogen, and oxygen, with the molecular formula H?[Si(W?O??)?]·nH?O and CAS number 12027-38-2.
Image of silicotungstic acid
Silicotungstic acid belongs to the Keggin-type polyoxometalates, with its core structure consisting of 12 tungsten-oxygen octahedra (WO?) surrounding a central silicon-oxygen tetrahedron (SiO?), forming a highly symmetrical cage-like anion [SiW??O??]??. This unique structure endows it with distinctive physicochemical properties: it appears as a white or pale yellow crystalline powder with a density of approximately 2.099 g/cm3, exhibiting acidity, catalytic activity, oxidative properties, good flowability, chemical stability, and solubility. However, it is sensitive to heat; under elevated temperatures, it readily loses its crystal water and may decompose into WO?, SiO?, and other oxides.
The non-ether method for preparing silicotungstic acid offers notable environmental and economic advantages. The core process includes:
Raw Material Conversion: Using ammonium paratungstate as the starting material, it is heated in a reactor, with dilute nitric acid added dropwise to adjust the pH while stirring, converting it into ammonium metatungstate.
Silicotungstate Coordination: The ammonium metatungstate solution is mixed with silica sol in a specific ratio, and ammonia water is added to adjust the pH. The mixture is reacted in a water bath for several hours, with reaction time and temperature controlled to ensure the formation of a stable (NH?)?[SiW??O??] solution.
Ion Exchange: A strong acidic cation exchange resin is used to replace ammonium ions, passing the (NH?)?[SiW??O??] solution through a resin column at a controlled flow rate to obtain a H?SiW??O?? solution.
Concentration and Crystallization: The exchanged solution is concentrated in a vacuum evaporator and then transferred to a crystallizer for slow cooling and crystallization. After centrifugal separation and low-temperature drying, a high-purity silicotungstic acid hydrate product is obtained.
Image of silicotungstic acid
Leveraging the high density of silicotungstic acid solutions, it can be formulated into heavy liquids for mineral flotation. It forms specific precipitation reactions with alkaloid compounds, producing stable polyoxometalate salts. The precipitate amount can be measured using gravimetric or spectrophotometric methods, achieving a detection limit as low as 0.1 μg/mL, widely used in traditional Chinese medicine analysis and drug quality control. As an efficient mordant for basic aniline dyes, it enhances dye-fiber bonding by forming coordination complexes with dye molecules. In photochromic material research, silicotungstic acid, when doped into silica nanofilms, imparts unique optical response properties to the material.
